Simple SysML for Beginners: Using Sparx Enterprise Architect

Overview

Simple SysML for Beginners: Using Sparx Enterprise Architect is for Beginners. This book is for beginning modelers who have just purchased a copy of Enterprise Architect and are anxious to get started, but otherwise don't know too much about SysML and don't have much experience using Enterprise Architect or any other similar tool. The purpose of this book is to help the reader get through the initial learning curve and start the reader on the way to becoming proficient at SysML modeling.

The book is designed to be a tool companion for three of the more comprehensive books on SysML:

• SysML Distilled: A Brief Guide to the Systems Modeling Language by Lenny Delligatti
• A Practical Guide to SysML, Third Edition: The Systems Modeling Language by Sanford Friedenthal et al
• Agile Systems Engineering 1st Edition by Bruce Powel Douglass

Together, these three books provide in-depth coverage of SysML. However, these books show only finished diagrams. They don’t cover the steps needed to construct the models and the diagrams. These steps can be remarkably complicated; the sequence of steps needed to construct the underlying model for a diagram is often less than obvious when using a real SysML tool. The goal of Simple SysML for Beginners: Using Sparx Enterprise Architect is to get you comfortable enough with Enterprise Architect and the basics of SysML so that you can confidently construct common models. This book covers all nine SysML diagram types, showing detailed steps to construct simple models that demonstrate key concepts for each diagram type. If you work your way through all of the examples in this book, you should be on a strong footing to tackle more complex modeling problems when they come your way.

ENTERPRISE ARCHITECT is a trademark of Sparx Systems Pty Ltd.

Benefits

• quick start with the tool
• simple SysML modeling examples
• 50+ example models
• 400+ annotated screen captures
• solid foundation for further study

Limitations

• Requirements Engineering - This book is not an exhaustive text on requirements engineering. However, the "Further Reading" appendix does list a number of excellent books for deeper understanding of this topic.
• Tool Version - The first edition of this book was authored primarily on Enterprise Architect version 14. There are minor differences in the procedures for later versions of the tool.
• Tool Manual - This is a beginner's introduction and is not a comprehensive reference for every feature of the tool.

Print Edition - Direct Orders

Asatte Press offers a standard 25% off of the list price of $57.95 for customers able to order direct from Asatte Press and pay by credit card. Orders can be shipped from the United States, Australia, or the United Kingdom.

Volume discounts are available for bulk orders of 10 or more books. A special program is available for bookstores.

Note that European Union customers will need to provide an EORI for some business that can act as the receiving legal entity for the book(s). European customers will also need to pay the book VAT for the country of delivery to the courier delivering the book(s).

For more information please contact: sales@asattepress.com

Special Sale!

The current shipping version of the book is V1.0.2. However, we have a small number of the previous V1.0.1 version in stock. These are incorrectly identified as V1.0.0 on the rear cover, but are properly identified as V1.0.1 on the copyright page.

A detailed errata listing the differences between the version levels is avialble here: Eratta for Simple SysML Sparx 1ED

For customers who don't mind working with a slightly downlevel book and an errata PDF and can pay by credit card, we are selling these cosmetic reject copies at at a 48% discount off of the list price. For more information please contact us at: sales@asattepress.com.

Kindle Version - Choice of Device

This book contains numerous color images of the tool which are necessarily intricate. Fortunately, there are many good (even free) options for reading the electronic version of this book and viewing the images. See eReader Application Note for more information about different eReader platforms for Asatte Press publications as well as recommendations for the most effective platforms for self-study.

Updated 15 May 2023
